2007 KONA MTB DIRT JUMP
（コナ マウンテンバイクダートジャンプ シリーズ）
ご注文、ご質問に便利な注文フォームをご用意しました。
スペック
| SHERD | SCRAP | STUFF | COWAN | |
| Frame sizes | 13"(XS), 15"(S), 15.5"(M) | 13"(XS), 15"(S), 15.5"(M) | 13"(XS), 15"(S), 15.5"(M) | 13"(XS), 15"(S), 15.5"(M) |
| Frame tubing | Kona Clump 7005 Aluminum | Kona Clump 7005 Aluminum | Kona Clump 7005 Aluminum | Kona Clump 7005 Aluminum |
| Fork | MARZOCCHI DIRT JUMPER 4 100mm travel Braze-on fittings 2 bottles, fender |
Marzocchi DIRT JUMPER 3 100mm travel Braze-on fittings 1 bottle, fenders |
MARZOCCHI DIRT JUMPER 3 100mm travel w/20mm Dropout Braze-on fittings 1 bottle, fenders |
MARZOCCHI DIRT JUMPER 2 100mm travel w/20mm dropout Braze-on fittings 1 bottle, rear disc mount, headtube detangler |
| Headset | TH w/Big Nut | TH w/Big Nut | TH w/Big Nut | TH w/Big Nut |
| Crankarms | FSA Gravity Alpha Drive ISIS | FSA Gravity MOTO-X MegaExo | FSA Gravity MOTO-X MegaExo | FSA Gravity MOTO-X MegaExo |
| Chainrings | PC Guard /36/24 | RG/36/24 | RG/36/24 | 36T |
| B/B | RPM ISIS DH | FSA Gravity MOTO MegaExo | FSA Gravity MOTO MegaExo | FSA Gravity MOTO MegaExo |
| Pedals | Kona Jackshit | Kona Jackshit | Kona Jackshit | Kona Jackshit |
| Chain | Shimano IG-70 | Shimano IG-70 | Shimano IG-70 | Shimano CN-HG53 |
| Freewheel | Shimano CS-HG30 (11-32t, 8speed) | Shimano CS-HG30 (11-32t, 8speed) | Shimano Deore (11-32t, 8speed) | Shimano Deore (11-32t, 9-speed) |
| F/D | Shimano Acera-x | Shimano Alivio | Shimano Alivio | Cowan/Jackshit Chainguide |
| R/D | Shimano Altus | Shimano Alivio | Shimano Alivio | Shimano Deore LX |
| Shifters | Shimano Alivio | Shimano Alivio | Shimano Alivio | Shimano Deore (right side only) |
| Handlebar | FSA Gravity Maximus OS Riser | FSA Gravity Maximus OS Riser | FSA Gravity Maximus OS Riser | FSA Gravity Maximus OS Riser |
| Stem | FSA Gravity Maximus OS | FSA Gravity Maximus OS | FSA Gravity Maximus OS | FSA Gravity Maximus OS |
| Grips | Cowan Signature | Cowan Signature | Cowan Signature | Cowan Signature |
| Brakes | Hayes MX4 Mechanical | Hayes SOLE V6 w/HFX-9 blade | HAYES HFX-9 XC V6 w/BFL Lever | HAYES HFX-9 XC V6 w/BFL Lever |
| Brake Levers | Avid FR-5 | Hayes SOLE V6 w/HFX-9 blade | HAYES HFX-9 XC V6 w/BFL Lever | HAYES HFX-9 XC V6 w/BFL Lever |
| Front hub | KK Disc | hub KK Disc | KK Disc 20mm | KK Disc 20mm |
| Rear hub | Shimano FH-M475 disc | Shimano FH-M475 disc | Shimano FH-M475 disc | Shimano FH-M475 disc |
| Spokes | Stainless 14g | Stainless 14g | Stainless 14g | Stainless DT 14g |
| Tires | Maxxis High Roller 26x2.35 | Maxxis High Roller 26x2.35 | Maxxis High Roller 26x2.35 | Maxxis Holy Roller 26x2.4 front, 26x2.2 rear |
| Rims | Alex DM-24 | Alex DM-24 | Sun Ditch Witch | Sun DitchWitch |
| Saddle | Kona DJ | Kona DJ | Kona DJ | Kona DJ |
| Seatpost | FSA FR-270 DBL | FSA FR-270 DBL | FSA FR-270 DBL | FSA FR-270 DBL |
| Seat clamp | Kona QR | Kona QR | Kona QR | Kona QR |
| Color | Grey Matt | Bright Blue Matt | Dark Grey Matt | Brown Matt |
フレームジオメトリー
SHERED/SCRAP/STUFF/COWAN
| Frame size | 13"(XS) | 15"(S) | 15.5"(M) |
| Head angle | 68.2° | 68.2° | 68.3° |
| Seat angle | 71.2° | 71.2° | 71.3° |
| Top tube | 21.5” | 22” | 23.3” |
| Chain stay | 16.7" | 16.7" | 16.7" |
| Head tube | 4.7" | 4.7" | 4.7" |
| BB height | 13" | 13" | 13" |
| Standover | 29.5" | 30.1" | 30.1" |
